| SWITCH DLINK | |
|---|---|
| NUMBER OF PORTS | • Five 10/100 Mbps LAN ports |
| SWITCHING FABRIC | • 1 Gbps switching fabric |
| Standard | • IEEE 802.3 10BASE-T • IEEE 802.3u 100BASE-TX • IEEE 802.3x Flow Control • IEEE 802.3az Energy-Efficient Ethernet (EEE) |
| Data Transfer Rates | • Ethernet: • 10 Mbps (half duplex) • 20 Mbps (full duplex) • Fast Ethernet: • 100 Mbps (half duplex) • 200 Mbps (full duplex) |
| Media Interface Exchange | • Auto MDI/MDIX adjustment for all ports |
| LED Indicators | • Per port: Link/Activity/Speed • Per device: Power |
| Transmission Method | • Store-and-forward |
| MAC Address Table | • 2,000 |
| Packet Filtering/Forwarding Rates (half duplex) | • Ethernet: 14,880 pps per port • Fast Ethernet: 148,800 pps per port |
| RAM Buffer | • 96 KB per device |
| Power Consumption | • Power On (Standby): 0.4 watts • Maximum: 0.784 watts |
| MTBF | • 1,785,631 hours |
| DIMENSIONS (L X W X H) | • 88 x 48 x 21.45 mm (3.46 x 1.89 x 0.84 inches) |
| Weight | • 43.4 grams (1.6 ounces) |
Thông số kỹ thuật
Mô tả sản phẩm
The DES-1005C and DES-1008C 10/100 Mbps Unmanaged Switches are economical, plugand-play networking switch solutions for SOHO and small and medium businesses wanting to benefit from the increased bandwidth of Fast Ethernet. They provide five or eight 10/100 Mbps ports that enable you to easily expand your network and provide a quick way to upgrade your network to fast connectivity
Fast Networking Made Easy
With data transfer speeds of up to 200 Mbps at full duplex, these switches are ideal for quick file transfers, online gaming and smooth streaming media. They feature easy-to-access Ethernet ports with LED indicators per port to easily distinguish link status. Auto MDI/MDIX crossover makes connection a cinch; just plug in your cables and you’re ready to go.
Conserve Energy
The DES-1005C and DES-1008C implement 802.3az Energy Efficient Ethernet, which saves energy and reduces heat automatically without sacrificing performance or functionality. The switches can detect when a connected computer is shut down or when there is no Ethernet traffic, and will put the port in standby mode, saving a substantial amount of power. In addition, the switch optimizes power usage for each port for the length of cable connected to it, using only as much power as is required. Both of these features work together to help you save power automatically.
